51348 | WIX SPIN-ON ELEMENT | $9.79 Each | (12 per carton*) | In Stock |
***Image may vary***

0-451-103-012 | Bosch | Spin-On Element | OFS # 97-25-0349

  • $7.81


SPIN-ON ELEMENT Spin-On Element
In Stock

Performance Data
Micron Rating:  25.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  75 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Change out Differential Pressure:  20 PSID



Dimensional Specifications
Outer Diameter, Top:  3.70 Inches   (93.98 MM)

Outer Diameter, Bottom:  3.70 Inches   (93.98 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  3.88 Inches  (98.55 MM)

Thread:  3/4-16 UNF-2B



Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Type of End-cap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

ConfEND

iguration:  SINGLE OPEN



 Filter-Mart Corp 33-7989

Packaging Specifications
Number per Carton:  12

Carton Weight:  13.30 LB

(Please contact for availability of broken cases)

WIX Filters White & Black Logo Compact (160x160)

Click Here For WIX Filters Cross Reference Tool

***All Online Filter Supply replacement parts are equivalent to or interchangeable with original manufacture parts, Names and part # used for cross reference only.***
